Delve into the Depths with HDS PRO 9

Experience unparalleled clarity with the HDS PRO 9 fishfinder/chartplotter. Witness real-time fish reactions with the cutting-edge ActiveTarget® 2 Live Sonar and pinpoint the most promising fishing spots with ultra-high-definition Active Imaging™ HD Transducer. Navigate confidently with preloaded C-MAP® DISCOVER OnBoard charts and enjoy a fully integrated boat control system.

Inside the Treasure Box

• HDS PRO 9 fishfinder/chartplotter with a 9-inch display screen
• Preloaded C-MAP DISCOVER OnBoard
• Lowrance Active Imaging HD 3-in-1 Transducer

Transducer Tech Details

• High-definition SideScan and DownScan Imaging™ for clear underwater images
• Lowrance® CHIRP offering superior clarity and target differentiation
• Effortless fish identification with FishReveal™ DownScan view
• Support for a wide range of CHIRP frequencies
• Designed for optimal signal clarity
• Direct compatibility with HDS PRO and other specified modules

Features Unveiled

• Preloaded C-MAP DISCOVER OnBoard charts with vast US and Canadian Lakes data
• Crystal-clear SolarMAX™ HD Touchscreen
• Support for high-definition Active Imaging™
• ActiveTarget 2 Live Sonar integration
• Instant mapping with C-MAP Genesis Live
• Touchscreen controls for various onboard systems
• Extensive connectivity options including NMEA 2000, wireless, and Bluetooth

Crystal-Clear Display Specs

• Backlight: Pure white LED
• Display Resolution: 1280 x 720
• Optimal Viewing Angles: 80° in all directions

Stay Connected Onboard

• Bluetooth: Integrated 4.0 with classic support
• Efficient Ethernet Ports: 2 x 100 Mbit
• WiFi: Internal 802.11b/g/n and WiFi-1 Module compatibility
• NMEA 2000 Connectivity
• Storage: 2 micro SD card slots (up to 32GB)

Power and Performance

• Maximum Power Consumption: 2.9A @ 13.8VDC
• Typical Power Consumption: 2.0A @ 13VDC
• Recommended Fuse Rating: 3A
• Supply Voltage: 12 v DC

Weather the Elements

• Operating Temperature: 5°F to 131°F
• Storage Temperature: 4°F to 140°F

Global Positioning Simplified

• GPS Receiver Channels: 16
• Update Rate: 10 Hz

Multi-Function Display Prowess

• Included Cartography: C-MAP Discover OnBoard and other models
• Internal Storage: 8.0 GB
• 3000 Waypoints, 100 Routes, and vast track recording capabilities
