Newmar Power - AC-IX Panel

Comprehensive Power Management for Marine Vessels

The Newmar AC-IX Panel is designed to offer unparalleled control and protection for your vessel’s AC power systems. Whether utilizing shore power or a generator, this panel ensures safe and efficient management of your marine electrical systems.

General Description

The Newmar AC-IX Panel is an essential component for managing AC power on board. Featuring a double-pole master breaker, it safeguards both the hot and neutral legs of the AC circuit. An integrated power-on indicator light provides real-time status updates, while a reverse polarity light alerts you to any wiring issues that could pose a shock hazard. With a 30 amp master breaker and a capacity for five branch circuits, this panel is versatile and reliable, making it perfect for a wide range of marine applications.

Key Features

• Double-Pole Master Breaker: Ensures protection for both hot and neutral legs of the AC circuit.
• Power-On Indicator Light: Provides clear visibility of the panel's operational status.
• Reverse Polarity Warning: Alerts you to any wiring issues, preventing potential electrical hazards.
• Versatile Capacity: Includes a 30 amp master breaker (optional 15A or 50A), with five branch circuits, four of which are installed standard (1-10A, 2-15A, 1-20A).

Technical Specifications

• Cut-Out Dimensions: 4 x 6 inches (10.2 x 15.2 cm)
• Weight: 2 lbs.
• Branch Circuit Capacity: 5 circuits (4 installed standard: 1-10A, 2-15A, 1-20A)

Product Dimensions

• Panel Size: 4 x 6 inches (10.2 x 15.2 cm)
• Weight: 2 lbs.

Highlights

• Easy Installation: Compact design with clear indicator lights for straightforward installation and monitoring.
• Enhanced Safety: Reverse polarity warning ensures immediate visibility of any wiring issues, reducing the risk of electrical shock.
• Customizable Options: Available with 15A, 30A, or 50A master breaker configurations to meet various electrical requirements.

Applications

Ideal for any marine vessel requiring reliable AC power management, the Newmar AC-IX Panel is perfect for both leisure and commercial boats. It provides essential control and protection, ensuring your onboard electrical systems operate safely and efficiently.

Ensure Reliable AC Power Control

The Newmar AC-IX Panel offers robust features and customizable options, making it a vital addition to any marine electrical system. Its comprehensive protection and user-friendly design ensure your vessel’s electrical systems are always safe and efficient.
