Vibrant and Versatile Marine Accent Lighting

The SHADOW-CASTER™ Marine Mini Neon Light Strip is designed to provide stunning, diffuse RGB lighting to accent key areas of your boat. Whether illuminating hatches, steps, coves, shelves, or compartments, this high-quality light strip enhances visibility and ambiance. Ideal for center console boats, fishing boats, pontoon boats, sports boats, and yachts, the Mini Neon Light Strip ensures a seamless, modern lighting effect while maintaining durability for marine environments.

Slightly smaller than the standard SCM-AL-NEON model, the SCM-AL-MINI-NEON features a tighter bend radius and a greater LED density per meter, offering enhanced flexibility and a smoother, more continuous lighting appearance. Its integrated light diffuser ensures a uniform glow, making it the perfect choice for areas where the strip is visible.

The strip is available in 8-foot and 16-foot lengths and can be customized by cutting at designated segments. With no integrated control electronics, it can either be hardwired for a fixed color or connected to a SHADOW-CASTER™ marine LED controller for full control over color and brightness.

Advanced Technical Features for Marine Use

• RGB color output for customizable lighting
• 120° beam angle for wide illumination coverage
• 120 LEDs per meter for high-density lighting
• 25mm cut segments for precise customization
• 15W per meter power consumption
• 1.2A per meter current draw
• 12V DC operation for marine applications
• 1-inch (25mm) bend radius for enhanced flexibility
• Durable silicone jacket material for protection
• IP67 waterproof rating for marine-grade durability
• Operational temperature range: -30°C to 60°C
• 20ft (6m) lead wire for easy installation

Compact and Flexible Dimensions

• Cross-section dimensions: 0.4 inch x 0.4 inch (10mm x 11mm)
• Available in 8-foot and 16-foot lengths

Built for Harsh Marine Environments

The SHADOW-CASTER™ Marine Mini Neon Light Strip is designed to withstand the rigors of marine conditions. The IP67-rated waterproofing and silicone jacket construction ensure resistance to water, salt, and UV exposure, making it a reliable choice for long-term marine applications.

Key Highlights

• Compact design with high-density LED arrangement
• Diffused lighting effect for a seamless glow
• Highly flexible with a small bend radius
• Fully waterproof and suitable for exterior and interior use
• Compatible with SHADOW-CASTER™ LED controllers for advanced lighting control

Available Variants

• SCM-AL-MINI-NEON-16 – 16-foot length
• SCM-AL-MINI-NEON-08 – 8-foot length
