Johnson Pump - Viking Power 16 Waste Pump

Quiet and Powerful Waste Pumping Solution

Introducing the Johnson Pump Viking Power 16 Waste Pump, a versatile and efficient solution designed to handle wastewater and bilge pumping needs on any leisure craft. This modern, single-chamber, self-priming diaphragm pump is engineered for easy installation and reliable performance. Whether you need to manage wastewater or bilge water, the Viking Power 16 offers a robust and dependable solution, ensuring smooth operation in all marine conditions.

Superior Features for Optimal Performance

The Viking Power 16 Waste Pump is built with advanced features that set it apart from other pumps on the market. Its non-choke valves eliminate the need for in-line filters, allowing for hassle-free operation. The pump can run dry and handle a mixture of air and water without any issues, making it highly reliable in diverse marine environments. With a self-priming height of up to 3 meters, it provides excellent suction power, while the low pulse and muffled rubber bracket ensure quiet operation.

Key Benefits:

• Self-Priming Capability: Self-primes up to 3 meters, providing strong suction power.
• Non-Choke Valves: No in-line filters required, simplifying maintenance.
• Run Dry Capability: Can handle dry running and air-water mixtures without damage.
• Quiet Operation: Low pulse and muffled rubber bracket for minimal noise.
• Easy Maintenance: Replaceable nitrile rubber diaphragm without removing the pump from the system.
• Versatile Connections: Delivered with 1" and 3/4" hose, 1/2" BSP KlickTite™ XL connectors; optional 90° KlickTite™ XL connectors available.

Technical Specifications

• Capacity (Open Flow): 16 l/min (4.2 GPM)
• Capacity at 0.1 bar: 15 l/min (4.0 GPM)
• Max Lift: 3 meters (9.8 feet)
• Max Head: 3 meters (9.8 feet)
• Connections: KlickTite™ XL connectors for 1" hose, 3/4" hose, and 1/2" BSP threads; straight and 90° (optional)
• Voltage: Available in 12V and 24V variants

Compact and Durable Design

The Viking Power 16 Waste Pump features a compact design that facilitates easy installation anywhere after the drain outlet in the wastewater system or as a bilge pump. Its durable construction ensures longevity and reliable performance, making it an excellent choice for marine applications.

General Dimensions

Designed to fit seamlessly into various marine setups, the Viking Power 16 Waste Pump's dimensions allow for flexible installation while providing powerful performance.

Sleek and Functional Finish

Crafted with high-quality materials, the Viking Power 16 Waste Pump combines durability with a sleek design. The pump's construction is built to withstand the harsh marine environment, ensuring long-lasting use and consistent operation.

Product Variations

1. 12V Version:

• Model: 10-13350-03
• Voltage: 12V
• Ideal for standard marine electrical systems, providing efficient waste management.

1. 24V Version:

• Model: 10-13350-04
• Voltage: 24V
• Suitable for higher voltage systems, offering the same reliable performance in a different electrical configuration.

Comprehensive Highlights

• Efficient Waste Management: High flow rate for effective wastewater and bilge water pumping.
• Advanced Protection: Built-in features prevent clogging and ensure smooth operation.
• Versatile Use: Suitable for various marine applications, including new and used leisure crafts.
• Easy Installation and Maintenance: Simplified setup and upkeep for continuous performance.

The Johnson Pump Viking Power 16 Waste Pump is the ultimate choice for efficient and reliable waste management on marine vessels. Its advanced features, robust construction, and versatile capabilities make it an essential addition to any marine system, ensuring optimal performance and peace of mind. Choose the Viking Power 16 Waste Pump for superior waste management solutions on the water.
